华硕 19V 4.74A 5.5*2.5mm

  • Features
  • Specification
  • Application
  • Typical models
  • Download

型    号：CP090-AU9
更新日期：2013.08.26
输入电压：AC90-264V 50/60HZ
输出电压：DC 19V
输出电流：4.74A
最大功率：90W
输出接头：Φ5.5×Φ2.5mm
效率：90%
输入AC接头：3pin
产品颜色：黑
规格尺寸：124*51*30mm
重量：362G
贮存温度：-15~50℃
工作温度：0~40℃
过压保护：有
过流保护：有
短路保护：有
过功率保护：有
制造厂家：深圳华巴源能科技有限公司& 奥斯汀科技（深圳）有限公司





Fit Machine Models

A6 Series: A6, A6JA, A6JC, A6Jm, A6K, A6KM, A6KT, A6M, A6T, A6Ta, A6Tc, A6R, A6VA, A6VM


A7 Series: A7C, A7D, A7F, A7G, A7J, A7Jc, A7M, A7S, A7Tc, A7V, A7Vc


A8 Series: A8F, A8Jc, A8Jp, A8Jr, A8Js, A8M, A8Sc


F2 Series: F2J, F2Je


F3 Series: F3Ja, F3Jc, F3Jm, F3Jp, F3Jr, F3M, F3P, F3Sc, F3T, F3Tc


F9 Series: F9F, F9J


G Series: G1, G1S, G2, G2S


M2 Series: M2000, M2000N


M6 Series: M6000N, M6700N, M6800N, M6B00N, M6N, M6V, M6VA


W3 Series: W3N, W3, W3V, W3000, W3000V


W5 Series: W5F, W5V


U5 Series: U5A, U5F


V1 Series: V1J, V1Jp


W2 Series: W2J, W2Pc, W2V
